25' Heavy-Duty Tape Measure

Performance Tool

  • Rubber coated, high-impact ABS case provides a secure grip for one-handed use

  • Auto-lock mechanism holds the tape measure blade firmly in place as it is extended for easy handling

  • Extra-wide thumb release provides full control to prevent damage to the blade or user during retraction

  • High-performance heat-treated spring provides consistently smooth blade retraction

  • Nylon coated 1 inch wide, 0.14mm thick blade delivers over 8 feet of standout and salt tested at 5X longer wear resistance than a non-coated tape

  • High accuracy, MID class-2 certified measurements printed in black/red on both sides of the yellow blade: SAE standard on top and SAE/ fractional/ metric on the bottom

  • Dual-sided triple riveted end hook slides to provide accurate inside/outside measurements and easily grabs an edge from any angle

  • Belt clip and woven wrist strap for convenient carrying and easy access

Warranty: Lifetime


Auto Retract Yes
Belt Clip Yes
Blade End Design Double Hook
Lockable Yes
Magnetic No
SAE or Metric Both
Series Black Armor
Standout Length (ft) 8 ft.
Stud Marks No
Tape Color Yellow
Tape Length (in) 25 ft.
Tape Width (in) 1 in.


Quantity UPC Width Depth Height Weight
Each 039564124457
Inner 12 10039564124454 6.50 14.20 3.50 12.10
Master 24 20039564124451 6.70 14.40 7.10 26.40
Standard Pack 1
